Soundcare® SuperSpike: You can’t do better !!!
Threadsize information:
- It can be smart to measure your old spikes before you buy. Here you have some thread specifications:
- M6 --> 6mm outher diameter --> 10 threads per cm
- M8 --> 8 mm outher diameter --> 8 threads per cm
- M10 --> 10 mm outher diameter --> 6,67 threads per cm (supported with combination M6 spikes and M6 to M10 threadconverter).
- M12 (NOT SUPPORTED) --> 12 mm outher diameter --> 5,7 threads per cm
- 1/4" --> 1/4 inch = app. 6,35 mm outher diameter --> 20 threads per inch = app. 7,8 threads per cm.
- 5/16" --> 5/16 inch = app. 7,94 mm outher diameter --> 18 threads per inch = app. 7,05 threads per cm.
- 3/8" --> 3/8 inch = app. 9,3 mm outher diameter --> 16 threads per inch = app. 6,45 threads per cm.
(supported with combination 1/4” spikes and 1/4” to 3/8” threadconverter).
- 7/16" (NOT SUPPORTED) --> 7/16 inch = app. 10,1 mm outher diameter --> 14 threads per inch = app. 5,65 threads per cm.
- 1/2" (NOT SUPPORTED) --> 1/2 inch = app. 12,4 mm outher diameter --> 12 threads per inch = app. 4,85 threads per cm.
Some speaker brand names and the most common threadsizes to use:
The threadsizetable is only guiding. Please check your old spikes before ordering.
Soundcare does not have any responsibility if the threadsize on your speakers vary from the sizes in the table.
Speaker
Threadsize
Acqustic Energy
M8
ATC
M5 (not supported)
ALR/Jordan
M8
Amphion
M6
Apertura
M8
AR
M6
Atacama
M6
Audio Vector M3
M6
Audio Vector S6
M8
Audio Pro Black Diamond
M6
Avantgarde
M8 & M10
BOLTZ USA
5/16"
B&W
M6 & M8 & M10
Boston
1/4"
Canton
M6
Castle Acoustics
M6 & M8
Celestion
M6
Chalio
M6
Coincident
1/4"
Dali
M6 & M8 & M10
Dynaudio
M8 % M10
Dynavoice
M6
Empire M
M8
Energy
1/4" & M6
Forsman
M8
Gale
M6
Gradient
M6
Heco
M6 & M8
Highland Audio
M8
Infinity Alpha
M6
Infinity Kappa
M8
Infinity USA
1/4"
Jamo
M8
JBL
M6 & M8
JM Lab
M6 / M8
JPW
M8
Kef
M6
Kef Q
M8
Klipsch
M6 & 1/4"
Linn
M8
Magnat
M6
Martin Logan
1/4" & 5/16" & 3/8"
McIntosh
1/4"
Meadowlark (new models)
1/4"
Meadowlark (old models)
3/8"
Meridian
M6 & M8
Mirage
1/4"
Mission
M6 & M8
M.M.Sound
M6 & M8
Monitor Audio
M6
Monitor Audio Studio 50 & 60
M8 & M10 finethreads (not supported)
Monsoon
M6
Mordant Short
M6
Newform Research
1/4"
NHT
1/4"
Paradigm
M6
Patos Basic
M6
Patos Lyric
M8
PSB
1/4"
Phase Tech.
1/4"
Proac Studio/Resp.
M8 & (M6)
Pro Tech
M8
PSB
1/4"
QLN
M8
REL
M8
Ruark
M8
Snell
1/4" & 5/16"
Sonus Faber
M8
Sound Dynamics
1/4"
StandDesign
M8
System Audio
M8
Tannoy
M6 & M8
Target Racks
M6 & M8
TDL
M6
Thiel (CS1.6,.6,7.2)
5/16"
Totem
1/4"
Vanderstein
1/4"
Vantage
M8
Vienna Acoustics
M6
Wharferdale
M6
Wilson Beuesch
M8
Yamaha
M6
